The 535512-3 is a 24-position, dual-row receptacle from TE's AMPMODU Mod II series. All 24 positions are loaded with female socket contacts. The post finish is tin-lead (50.0 µinch), which is the solder-tail side and does not affect the mating interface. Current rating is 2 A per contact.
Right-angle through-hole — board-edge layout and solder termination
This is the standard configuration for edge-mount receptacles where the cable or mating header runs parallel to the board plane, keeping the z-height budget under the 0.238" (6.05mm) insulation height. The 0.115" (2.92mm) solder-tail length is designed for through-hole soldering on standard 0.062" (1.6mm) PCBs.
Active status, RoHS non-compliant — legacy-build sourcing
No stock-holding claim — each order is quoted to the requested volume.
Peer comparison — 535512-3 vs 1376775-2 vs 1-2823056-2
The 1376775-2 is a 5-position receptacle from the same AMPMODU Mod II family, rated 3 A with gold mating (8.00 µinch) and tin post finish — a lower-position, RoHS-compliant sibling with a thinner gold layer. The 1-2823056-2 is a 12-position dual-row receptacle from a different series (PA46 nylon), with tin-on-tin contacts rated at a thicker 118.1 µinch post finish but no gold on the mating face — a lower-cost option for single-mate applications where corrosion resistance is not critical. The 1376775-2 and 1-2823056-2 serve different position counts or plating grades and are not pin-compatible substitutes.
