TE Connectivity AMPMODU Mod II receptacle, order code 535676-5, 6 positions, single row, 0.100" (2.54 mm) pitch, gold-plated mating contacts, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Female Socket |
| Mounting | Through Hole, Right Angle |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Operating temperature | -55°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.137\" (3.47mm) |
| Insulation material | Polyester, Glass Filled |
| Style | Board to Board |
| Package | Tube |
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.115\" (2.92mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 50.0µin (1.27µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 535676-5 is a 6-position single-row receptacle from the TE AMPMODU Mod II series, configured as a board-to-board interconnect with through-hole right-angle mounting and solder termination.
TE Connectivity AMP Connectors lists the 535676-5 as Obsolete.
The 535676-5 is an Obsolete part. Availability is confirmed per RFQ — submit a request with the target quantity and the sourcing team will quote from available surplus inventory.
Any functional replacement would require a board spin — the pitch, footprint, and mounting are unique to this order code.
The 535676-5 carries RoHS and REACH compliance documentation from TE Connectivity AMP Connectors.
