16-Position Shrouded Header for Board-to-Board and Cable Interconnects
Contact Plating and Current Rating for Signal and Low-Power Duty
Each contact is rated at 3A continuous. In a 16-position header, the total current capacity is limited by the sum of adjacent contacts and the ambient temperature; derating applies above 25°C per the AMPMODU MTE derating curve. The square male pin measures 0.230" (5.84mm) mating length and 0.130" (3.30mm) post length, providing adequate engagement depth for standard AMPMODU receptacles.
Sourcing and Compliance for Production Builds
The base product number is 103635, which can be used to locate series-specific documentation and mating halves within the AMPMODU MTE family.
This header mates with AMPMODU MTE receptacle housings and crimp socket contacts. The keying slot prevents mismating in multi-connector harnesses. Termination is solder-through-hole; the 0.130" post length accommodates standard PCB thicknesses up to 0.062" (1.6mm). The insulation height of 0.200" (5.08mm) provides clearance for mating receptacle latch engagement.
