TE Connectivity AMP Connectors 6-103672-5 — Pin Headers

6-103672-5 TE Connectivity AMPMODU MTE Header, 16 Pos

MPN6-103672-5
Active

TE Connectivity AMP Connectors AMPMODU MTE header, 6-103672-5, 16 positions, 0.100" (2.54 mm) pitch, through-hole right-angle, shrouded four-wall, male pin, tin-plated contacts, rated 3 A, board lock and keying slot, UL94 V-0.

$2.4100Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesAMPMODU MTE
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

6-103672-5 key specifications
ParameterValue
SeriesAMPMODU MTE
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeLatch Holder
Current rating3A
Operating temperature-65°C ~ 105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.200\" (5.08mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

6-103672-5 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTube
FeaturesBoard Lock, Keying Slot
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions16
Contact finish - postTin
Contact length - post0.130\" (3.30mm)
Contact finish - matingTin
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

16-Position Right-Angle Header with Latch Retention

The 6-103672-5: This is a 16-position, single-row, right-angle header from the AMPMODU MTE series by TE Connectivity.

Shrouded, Keyed, and Board-Locked for Vibration Environments

The keying slot prevents inserting the wrong mating half in multi-connector panels — a common field issue when several similar headers sit side by side.

The base product number is 103672; the full 6-103672-5 is the specific configuration with tin plating, board lock, and keying slot. ROHS3 compliant.

Frequently asked questions

Does 6-103672-5 have a keying slot and board lock?

Yes — the features list includes a keying slot and a board lock. The keying slot prevents mis-mating; the board lock holds the header during soldering and resists cable strain.

What is the pitch of 6-103672-5?

The pitch is 0.100" (2.54 mm), standard for the AMPMODU MTE series and for many wire-to-board and board-to-board applications.

Is 6-103672-5 shrouded?

Yes — it is a shrouded header with four walls, which protects the male pins during handling and mating.
