Connector identity and board fit
The 6-103673-4: This is a 15-position, single-row shrouded header from the AMPMODU MTE series, designed for board-to-board or cable applications. Right-angle through-hole termination orients the header parallel to the board edge, keeping the mating axis low-profile. The 4-wall shroud protects the male pins from bending and guides the receptacle into alignment — a solid choice for harnesses that see repeated connect/disconnect cycles.
Current, plating, and environmental limits
Rated 3 A per contact — at this current the temperature rise stays within the UL94 V-0 thermoplastic housing limit. The gold mating finish (15.0 µinch) supports corrosion resistance in field-service environments and delivers a rated mating cycle life well beyond tin-plated alternatives. The latch holder fastening type provides vibration-resistant retention without requiring a secondary locking clip. Applications listed include automotive, general purpose, medical, and telecommunications — the combination of gold plating, wide temp range, and UL94 V-0 flammability rating supports equipment inside an enclosure requiring flame-rated components.
Sourcing and lifecycle status
No official successor or second-source cross-reference from TE Connectivity. The base product number 103673 identifies the series family; the full 6-103673-4 suffix specifies the 15-position, right-angle, gold-plated variant.
