TE Connectivity AMPMODU MTE series, 6-103673-9, a 20-position single-row right-angle through-hole header, 0.100" (2.54 mm) pitch, shrouded 4-wall, gold-plated mating contacts, board lock and keying slot, rated 3 A, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Features | Board Lock, Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Contact finish - post | Tin |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 6-103673-9: It mounts through-hole and exits the board at a right angle, keeping the mated connector parallel to the PCB — a fit for low-profile enclosures or board-edge cable exits. The keying slot prevents mating with an unkeyed receptacle, reducing mis-mate risk in multi-connector panels.
Rated 3 A per contact.
The keying slot on the header requires a receptacle with a matching keying feature — confirm the receptacle order code includes a keying slot or use a non-keyed receptacle if the slot is not engaged.
It is a single-row, 20-position header with all positions loaded. The keying slot is a physical notch in the shroud that aligns with a matching rib on the receptacle — it prevents mating with an unkeyed or differently keyed connector.
