TE Connectivity AMP Connectors 6-103908-9 — Pin Headers, Sockets & Housings

6-103908-9 TE AMPMODU MTE Header 20 Pos 2.54mm Gold

MPN6-103908-9
Active

TE Connectivity AMPMODU MTE series, 6-103908-9, single-row shrouded header, 20 positions, 0.100" (2.54mm) pitch, through-hole, press-fit/solder termination, gold-plated mating contacts, 3A rating, UL94 V-0, -65°C~105°C.

$5.9800Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 6-103908-9 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

6-103908-9 key specifications
ParameterValue
SeriesAMPMODU MTE
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLatch Holder
Current rating3A
Operating temperature-65°C~105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.535\" (13.60mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

6-103908-9 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTube
FeaturesKeying Slot
ShroudingShrouded - 4 Wall
TerminationPress-Fit, Solder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions20
Contact finish - postTin
Contact length - post0.130\" (3.30mm)
Overall contact length0.545\" (13.84mm)
Contact finish - matingGold
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

What this 20-position shrouded header brings to the board

Termination and mounting: press-fit or solder

The insulation height of 0.535" (13.60mm) gives clearance for the shrouding above the board. A keying slot is present on the header — this prevents inserting the mating connector in the wrong orientation, which is a real time-saver when you're working on a panel with multiple similar connectors. The header ships in a tube, and all 20 positions are loaded.

The base product number is 103908, which helps when searching for mating receptacles or alternate plating options within the AMPMODU MTE family.

Frequently asked questions

What is the mating connector for 6-103908-9?

The 0.100" pitch and single-row layout are standard across the series — look for a 20-position receptacle with the same keying slot orientation.
