TE Connectivity AMP Connectors AMPMODU System 50 header, 8 positions, 0.050" (1.27mm) pitch, through-hole, gold mating contacts, latch holder, UL94 V-0, -65°C to 105°C.
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 30VAC |
| Operating temperature | -65°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.390\" (9.91mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Circular |
| Rows | 1 |
| Pitch | 0.050\" (1.27mm) |
| Positions | 8 |
| Contact finish - post | Tin |
| Contact length - post | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.125\" (3.18mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 6-104071-0: Mates with any AMPMODU System 50 receptacle that shares the 0.050" pitch and 8-circuit layout — the latch holder on this header locks with the matching receptacle latch, preventing back-out under vibration.
The tin post finish (150.0µin) is the solder interface; no corrosion risk at the board joint.
The 30VAC rating is a signal-level voltage; this is not a power interconnect.
Yes, the fastening type is a latch holder — it locks with the matching receptacle latch to resist vibration-induced disconnection.
