TE Connectivity AMPMODU System 50 header, 6-104477-2, 10-position dual-row right-angle through-hole, 1.27 mm pitch, 30 VAC, gold-plated mating contacts, latch holder, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 30VAC |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.290\" (7.37mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Guide |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.050\" (1.27mm) |
| Positions | 10 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.145\" (3.68mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.125\" (3.18mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Use it for low-voltage logic, sensor signals, or data lines where the board-to-board or cable path needs 10 circuits in a narrow pitch.
The latch holder locks the mating connector in place, preventing back-out under vibration in automotive or industrial enclosures.
Yes, 6-104477-2 is ROHS3 compliant.
The mating pitch is 0.050 inch (1.27 mm), with a row spacing of 0.100 inch (2.54 mm).
