6-position dual-row shrouded header with latch lock
It mates with a matching receptacle that accepts the same 0.165 in (4.20 mm) pitch and latch-lock fastening. Key features include a shrouded 4-wall design for pin protection, latch lock for vibration-resistant mating, and through-hole solder termination.
Pitch and footprint matching
The 0.150 in (3.81 mm) post length fits standard through-hole boards; the 0.220 in (5.59 mm) mating pin length engages the receptacle contact. Compared to the 12-position sibling 1318699-3, the 640500-1 shares the same pitch, row spacing, and latch-lock style, but uses tin plating on both sides versus gold on the mating surface. The 6-position count suits lower-density harnesses where gold flash is not required.
