TE Connectivity AMP MR (Miniature Rectangular) header, order code 640501-2, 9 positions, 3 rows, 0.165" (4.20 mm) pitch, 6 A, 250 VAC, gold mating contacts, through-hole, solder termination, shrouded - 4 wall, latch lock.
| Parameter | Value |
|---|---|
| Series | MR (Miniature Rectangular) |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Lock |
| Voltage rating | 250VAC |
| Current rating | 6A |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black, Red |
| Insulation height | 0.531\" (13.50mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Circular |
| Rows | 3 |
| Pitch | 0.165\" (4.20mm) |
| Positions | 9 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.150\" (3.81mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.220\" (5.59mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 640501-2 is the 9-circuit, 3-row member of TE's MR (Miniature Rectangular) shrouded header line, rated 6 A per circuit at 250 VAC. Gold mating contacts on phosphor bronze terminals handle the current; the 4-wall shroud with latch lock resists vibration-induced disconnects in a board-to-cable/wire interface.
No peer order code with a documented cross-reference appears in the current record. Check the full MR series listing for same-position variants in different orientations or plating grades, or submit an RFQ with the base product number 640501 to surface available alternatives.
Board to Cable/Wire — it is a male header designed to mount on the board side and mate with a cable-side IDC or crimp receptacle housing.
