TE Connectivity AMP Connectors 640501-4 — Pin Headers

640501-4 TE Connectivity Header 9 Pos 4.2mm Pitch Gold

MPN640501-4
Active

TE Connectivity AMP MR (Miniature Rectangular) 640501-4, 9-position, 3-row, 0.165" (4.20mm) pitch header, board-to-cable/wire style, shrouded with latch lock, through-hole solder termination, gold-plated mating contacts (30.0µin), rated 6A at 250VAC, UL94 V-0, -55°C to 105°C.

$21.8200Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 640501-4 datasheet (PDF)
RoHSRoHS non-compliant
SeriesMR (Miniature Rectangular)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

640501-4 key specifications
ParameterValue
SeriesMR (Miniature Rectangular)
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLatch Lock
Voltage rating250VAC
Current rating6A
Operating temperature-55°C ~ 105°C
Contact materialPhosphor Bronze
Insulation colorBlack, Red
Insulation height0.531\" (13.50mm)
Insulation materialPolyamide (PA), Nylon

All specifications

640501-4 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageBulk
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose
Contact shapeCircular
Rows3
Pitch0.165\" (4.20mm)
Positions9
Row spacing - mating0.165\" (4.20mm)
Contact finish - postTin-Lead
Contact length - post0.210\" (5.33mm)
Contact finish - matingGold
Contact length - mating0.220\" (5.59mm)
Contact finish thickness - post150.0µin (3.81µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

9-position 4.20mm pitch header with gold contacts

The 640501-4 is a 9-position, 3-row header from TE's MR (Miniature Rectangular) series, on a 4.20mm pitch.

The 4.20mm pitch and 3-row layout match the MR receptacle footprint. Termination is through-hole solder; the contact length on the post side is 0.210" (5.33mm), which fits standard PCB thicknesses in the 1.6mm range.

RoHS status is non-compliant due to the tin-lead post plating — plan for exemption or alternate finish if RoHS compliance is required.

Frequently asked questions

What is the current rating of the 640501-4?

The 640501-4 is rated 6A per circuit at 250VAC. The gold-plated contacts keep contact resistance stable across the rated current range.

Is the 640501-4 compatible with Molex Mini-Fit Jr receptacles?

No — the 640501-4 is a TE MR series header and mates only with the corresponding MR series receptacle. The 4.20mm pitch and keying are specific to the MR family; Mini-Fit Jr uses a different housing geometry and latch position.

Does the 640501-4 have a latch lock feature?

Yes, the header uses a latch lock fastening type.
