TE Connectivity AMP Connectors MR (Miniature Rectangular) 640503-1, Board to Cable/Wire header, 15 positions, 3 rows, 4.20 mm pitch, shrouded - 4 wall, latch lock, through-hole solder, tin-plated phosphor bronze contacts, 6 A, 250 VAC, -55°C to 105°C, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | MR (Miniature Rectangular) |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Lock |
| Voltage rating | 250VAC |
| Current rating | 6A |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black, Red |
| Insulation height | 0.531\" (13.50mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Circular |
| Rows | 3 |
| Pitch | 0.165\" (4.20mm) |
| Positions | 15 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.150\" (3.81mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.220\" (5.59mm) |
This 640503-1 is a 15-position, 3-row header on a 4.20 mm pitch — the row spacing matches the pitch at 0.165" (4.20 mm), so the footprint is a uniform grid that simplifies PCB layout. The latch lock fastening holds the mating receptacle against vibration and cable tug, which matters for equipment that sees movement or shock.
It is a 15-position, 3-row header with a 4.20 mm pitch on both the row spacing and the pin-to-pin spacing — the grid is uniform at 0.165" (4.20 mm).
Yes, it is listed as ROHS3 Compliant.
