TE Connectivity AMP Connectors 7-338069-4 — Female Socket Headers

7-338069-4 TE Micro-MaTch 4-Position Receptacle

MPN7-338069-4
Active

TE Connectivity AMP Connectors Micro-MaTch, 4-position receptacle, 0.100" (2.54 mm) pitch, tin-plated forked contacts, surface-mount termination, friction lock, -40°C~105°C, UL94 V-0.

$1.3500Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMicro-MaTch
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

7-338069-4 key specifications
ParameterValue
SeriesMicro-MaTch
TypeForked
MountingSurface Mount
Connector typeReceptacle
Fastening typeFriction Lock
Voltage rating100VDC
Operating temperature-40°C~105°C
Contact materialPhosphor Bronze
Insulation colorRed
Insulation height0.209\" (5.30mm)
Insulation materialPolyamide (PA46), Nylon 4/6, Glass Filled
Material flammability ratingUL94 V-0

All specifications

7-338069-4 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesPick and Place
TerminationSolder
ApplicationsAutomotive, General Purpose
Rows2
Pitch0.100\" (2.54mm)
Positions4
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingTin

Product details

The 7-338069-4: Tin-on-tin works well in benign environments; for repeated mating cycles or corrosive atmospheres, a gold-plated sibling would be the better call.

The friction lock engages on the header latch to resist vibration-induced disconnect; it's not a secondary TPA, so terminal retention relies on the crimp terminal's own lance in the housing cavity. Solder termination means the contacts are reflowed to the PCB pads — no crimping or wire stripping needed at the board end. The forked contact geometry provides a compliant beam that wipes the header pin on insertion, cleaning through light oxide films common in tin-plated interfaces.

Frequently asked questions

What is the closest equivalent to 7-338069-4?

The closest functional equivalent in the same Micro-MaTch series is the 1-2823056-2, a 12-position receptacle with the same 2.54 mm pitch, tin plating, and SMD termination. The only difference is circuit count — 4 positions vs 12 — so it is not a direct pin-for-pin replacement unless your BOM allows unused positions.
