Board-fit overview: pitch, positions, and footprint
The forked contact style provides a wiping action on insertion, cleaning the mating surface for a reliable tin-to-tin connection.
Surface-mount assembly and pick-and-place readiness
This means it is ready for automated SMT assembly without manual handling — the cover tape and reel dimensions match standard feeder specs.
Material ratings and environmental range
Voltage rating is 100 VDC — this is a signal-level connector, not for power distribution. Current derating follows the contact temperature rise; tin-plated contacts typically carry 1-2 A per circuit at 2.54mm pitch, but the exact limit depends on the number of simultaneously powered circuits.
