TE Connectivity AMP Connectors Micro-MaTch series, 8-215464-4, 14-position, 2-row, 2.54 mm pitch, shrouded header, male pin, through-hole, press-fit/solder termination, latch lock, tin contacts, 1.5 A, 230 V, -40°C to 105°C, UL94 V-0, red insulation, active.
| Parameter | Value |
|---|---|
| Series | Micro-MaTch |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Lock |
| Voltage rating | 230V |
| Current rating | 1.5A |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Red |
| Insulation height | 0.142\" (3.60mm) |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Shrouding | Shrouded - 4 Wall |
| Termination | Press-Fit, Solder |
| Applications | General Purpose |
| Contact shape | Rectangular |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.122\" (3.10mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - mating | 118.1µin (3.00µm) |
Termination is through-hole with a press-fit, solder option — the 0.122" (3.10 mm) post length provides a solid anchor into the PCB. The red insulation colour aids visual identification on a populated board.
The 8-215464-4 is available through independent distribution. No stock-holding claim is made — each order is sourced per request.
The 8-215464-4 is a male pin header from the Micro-MaTch series. Confirm the mating half part number against your harness design.
