TE Connectivity AMP Connectors Micro-MaTch, 14-position dual-row SMT header, 2.54 mm pitch, shrouded 4-wall latch lock, tin-plated contacts, 1.5 A, -40°C to 105°C, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Micro-MaTch |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Lock |
| Voltage rating | 230V |
| Current rating | 1.5A |
| Operating temperature | -40°C~105°C |
| Contact material | Brass |
| Insulation color | Red |
| Insulation height | 0.181\" (4.60mm) |
| Insulation material | Polyamide (PA46), Nylon 4/6, Glass Filled |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Pick and Place |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Rectangular |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact finish thickness - mating | 118.1µin (3.00µm) |
The 8-338728-4: The 1.5 A rating is typical for tin-plated signal contacts — adequate for logic-level and low-power sensor lines, but not for power distribution.
Supplied in Tape & Reel packaging with a Pick and Place feature, this header is ready for automated SMT assembly — the flat top surface and vacuum-pick area allow the nozzle to seat without tipping.
