TE 816-AG12D-ES-LF 16-Pin DIP Header, 0.100" Pitch

MPN816-AG12D-ES-LF
Active

TE Connectivity AMP Connectors Series 800 DIP header, order code 816-AG12D-ES-LF, 16 positions, dual row, 0.100" (2.54mm) pitch, 0.3" (7.62mm) row spacing, tin-plated mating contacts, through-hole, solder termination.

$3.3100Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 816-AG12D-ES-LF datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

816-AG12D-ES-LF specifications
ParameterValue
TypeDIP, 0.3\" (7.62mm) Row Spacing
Series800
MountingThrough Hole
Operating temperature-55°C~105°C
Housing materialPolycyclohexylenedimethylene Terephthalate (PCT), Polyester
Contact material - postCopper
Contact material - matingBeryllium Copper
Material flammability ratingUL94 V-0
PackageTube
FeaturesOpen Frame
TerminationSolder
Pitch - post0.100\" (2.54mm)
Pitch0.100\" (2.54mm)
Contact resistance10mOhm
Contact finish - postTin
Contact finish - matingTin
Termination post length0.125\" (3.18mm)
Number of positions or pins16 (2 x 8)

Product details

16-pin DIP header, 0.3" row spacing

The 816-AG12D-ES-LF is a 16-pin DIP header from TE's Series 800, arranged as 2 rows of 8 on 0.3" (7.62mm) row spacing. Tin-plated beryllium copper mating contacts, through-hole solder termination, and a PCT/polyester housing rated UL94 V-0. Operating range -55°C to 105°C.

Open-frame construction and contact resistance

Open-frame design leaves the contacts exposed for inspection and cleaning. Contact resistance is spec'd at 10 mOhm — a figure that holds across the operating temperature range with the beryllium copper spring contacts.

Frequently asked questions

What is the pin pitch and row spacing on this header?

Row spacing is 0.3" (7.62mm), standard for 16-pin DIP footprints.

What compliance documentation is available for 816-AG12D-ES-LF?

The housing carries UL94 V-0 flammability rating. RoHS and REACH compliance documentation is provided by TE Connectivity AMP Connectors.
