TE Connectivity AMPMODU Mod II unshrouded header, 825440-5, 10 positions, dual-row, 0.100" (2.54mm) pitch, through hole, male pin, gold mating finish, UL94 V-0, active production.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Green |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Polybutylene Terephthalate (PBT) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 10 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Overall contact length | 0.500\" (12.70mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.264\" (6.70mm) |
| Contact finish thickness - post | 98.4µin (2.50µm) |
| Contact finish thickness - mating | 3.90µin (0.099µm) |
Green PBT insulation (UL94 V-0) provides good dimensional stability and flame resistance for equipment inside an enclosure.
Tin plating on the solder tail (98.4µin) ensures good solderability with standard lead-free processes.
ROHS3 compliant, with no known obsolescence risk for the near term.
Yes, 825440-5 is an unshrouded header — no side walls or keying ribs.
The mating pitch is 0.100" (2.54mm), with the same row spacing of 0.100" (2.54mm). This is the standard grid for prototyping and legacy designs.
