12-pin right-angle breakaway header
Board footprint and routing fit
The right-angle orientation means the header extends 0.264" (6.70 mm) from the board edge on the mating side, with a 0.126" (3.20 mm) solder tail length for through-hole soldering.
826634-6 TE Connectivity AMPMODU Mod II Header, 12 Pos
MPN826634-6
Active
TE Connectivity AMPMODU Mod II unshrouded breakaway header, 12 circuits, 0.100" (2.54 mm) pitch, right-angle through-hole, gold-plated mating pins, rated 5 A, RoHS, Active.
$1.5300Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesAMPMODU Mod II
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 5A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Green |
| Insulation height | 0.219\" (5.56mm) |
| Insulation material | Polybutylene Terephthalate (PBT) |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.264\" (6.70mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 3.90µin (0.099µm) |
Product details
Frequently asked questions
Where can I buy 826634-6 and how do I get a price?
826634-6 is available through independent distribution. Submit an RFQ for current pricing and availability — stock and lead time are confirmed at quote time against your BOM quantity.
