Board Layout Fit for a 14-Position Right-Angle Header
The 0.318" (8.08mm) mating pin length gives clearance for standard receptacles, while the 0.110" (2.79mm) post length suits typical 1.6mm-thick boards.
86479-5 TE Connectivity AMPMODU Mod II Header, 14 Pos
MPN86479-5
Active
TE Connectivity AMPMODU Mod II, 86479-5, 14 Position, 2 Row, 0.100" (2.54mm) Pitch, Right Angle, Through Hole, Unshrouded Header, Push-Pull, 3A, Gold Mating Finish
$8.2500Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesAMPMODU Mod II
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.238\" (6.05mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tray |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Gold |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | Flash |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the pitch and position count of 86479-5?
All positions are loaded.
Is the 86479-5 shrouded or unshrouded?
It is an unshrouded header with push-pull fastening — no locking latch. In a vibration-prone environment, consider a shrouded alternative with a latch lock if the board layout allows.
