87227-6 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

87227-6 TE Connectivity AMPMODU Mod II Header, 12 Pos

MPN87227-6
Active

TE Connectivity AMPMODU Mod II unshrouded header, 87227-6, 12 positions, dual-row, 0.100" (2.54 mm) pitch, through-hole solder termination, gold mating finish, 3 A, UL94 V-0.

$4.6400Ref. price · indicative, final on quote
87227-6 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

87227-6 Technical Specifications
ParameterValue
SeriesAMPMODU Mod II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C ~ 105°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.090\" (2.29mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions12
Row spacing - mating0.100\" (2.54mm)
Contact finish - postGold
Contact length - post0.125\" (3.18mm)
Overall contact length0.533\" (13.55mm)
Contact finish - matingGold
Contact length - mating0.318\" (8.08mm)
Contact finish thickness - postFlash
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Current and Contact: What 3 A Means on This Header

The 87227-6: For signal-level loads (logic, sensor, low-power), this is generous headroom; for power distribution, derate per the application's ambient temperature.

Mates with any AMPMODU Mod II receptacle or socket housing that accepts a 0.025" square pin on 0.100" centers — common mates include TE 1-87456-0 and 5-104809-0 series. Through-hole termination suits wave-solder or hand-solder assembly; the 0.125" post length fits standard 0.062" to 0.093" PCBs.

Frequently asked questions

What is the closest pin-compatible alternative to 87227-6 in the AMPMODU Mod II family?

Within the same series, a 12-position, dual-row, unshrouded header with 0.100" pitch and gold mating finish — the key variable is post length or plating thickness. The base product number 87227 covers multiple options; confirm the contact finish thickness (15 µinch gold here) and post length (0.125") against your receptacle's requirements.

Where can I buy TE Connectivity 87227-6?

Sourced to order against your BOM quantity. Availability and current pricing confirmed at quote time — submit an RFQ for this exact order code.
