87631-2 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE 87631-2 AMPMODU Mod IV Receptacle Housing, 6 Pos, 2.54mm

MPN87631-2
Active

TE Connectivity AMPMODU Mod IV receptacle housing, 87631-2, 6 positions, 2 rows, 0.100" (2.54mm) pitch, 0.100" row spacing, crimp termination, free-hanging, detent lock, black thermoplastic, -65°C to 105°C.

$1.3900Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

87631-2 Technical Specifications
ParameterValue
SeriesAMPMODU Mod IV
GenderFemale Socket
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeDetent Lock
Operating temperature-65°C ~ 105°C
ColorBlack
Insulation materialThermoplastic
NoteContacts Not Included
Pitch0.100\" (2.54mm)
PackageBulk
Row spacing0.100\" (2.54mm)
Rows2
Contact terminationCrimp
Positions6

Product details

6-Circuit Receptacle Housing on the 0.100" AMPMODU Grid

The 87631-2: It is a free-hanging (in-line) housing with a detent lock for secure mating, accepting female socket contacts that are crimped onto the wire.

Contacts Not Included — Order Separately

The 87631-2 is a housing only — contacts are not included. You will need to order the matching AMPMODU Mod IV female crimp socket terminals separately. This is a standard practice for modular connector systems where the wire gauge and plating requirements vary by application.

Mating and Termination

The crimp termination allows you to terminate wires in the harness shop and then stuff the contacts into the housing; the detent lock holds the pair together against moderate vibration.

Frequently asked questions

Where can I buy the 87631-2 and what is the price?

Current pricing and availability are confirmed at the time of quote — submit an RFQ for your target quantity.

What contacts work with the 87631-2?

The 87631-2 accepts AMPMODU Mod IV female socket crimp contacts. The exact terminal part number depends on your wire gauge and plating preference — TE offers tin and gold plating options for 22-26 AWG wire. The housing itself does not include contacts.
