TE Connectivity MCON series receptacle housing, 9-1563172-9, 58 positions, 4 rows, free-hanging (in-line), crimp termination, black PA66 housing, -40°C to 125°C, contacts not included.
| Parameter | Value |
|---|---|
| Series | MCON |
| Gender | Female Socket |
| Mounting type | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Operating temperature | -40°C ~ 125°C |
| Color | Black |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
| Note | Contacts Not Included |
| Package | Box |
| Features | Strain Relief |
| Rows | 4 |
| Contact termination | Crimp |
| Positions | 58 |
A built-in strain relief is integrated into the housing, which takes the cable pull load off the individual contact retention latches in a high-vibration harness.
Four rows of cavities in a free-hanging housing. The integrated strain relief grips the cable bundle to keep crimp terminals seated.
The housing ships empty — you must order the matching MCON female crimp terminals separately. The terminals are inserted into the cavities after crimping onto the wire. This is standard for MCON housings; the terminal part number is not the same as the housing.
This part is sourced to order.
