TE Connectivity AMP Connectors Micro-MaTch receptacle, 20 positions, 0.100" (2.54mm) pitch, dual-row, surface-mount, tin-plated forked contacts, rated for automotive and general-purpose use.
| Parameter | Value |
|---|---|
| Series | Micro-MaTch |
| Type | Forked |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Voltage rating | 100VDC |
| Operating temperature | -40°C~105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Red |
| Insulation height | 0.209\" (5.30mm) |
| Insulation material | Polyamide (PA46), Nylon 4/6, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Pick and Place |
| Termination | Solder |
| Applications | Automotive, General Purpose |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
It is ROHS3 compliant, meeting current EU substance restrictions.
The closest functional alternative is the 1-2823056-2 — a 12-position version of the same Micro-MaTch receptacle, also tin-plated and SMT, but in a black housing. For higher mating-cycle requirements, the 1376775-2 offers gold-plated contacts (8.00µin) at 3 A rating, though in a 5-position, box-packaged format.
Yes, the 9-188275-0 is ROHS3 compliant, meeting the latest EU RoHS substance restrictions.
The 9-188275-0 is a receptacle that mates with a 0.100" pitch pin header (male pins) from the Micro-MaTch series. The matching header is typically a 20-position, dual-row, through-hole or SMT pin header with the same pitch and row spacing.
