6.50 mm Pitch, 12-Circuit Power Double Lock Header
Locking Ramp and Mating Half
The locking ramp on the 917353-1 engages with the matching Power Double Lock receptacle housing — the ramp snaps into the receptacle latch window, holding the pair mated under cable strain and vibration. No secondary lock is needed for most applications. The mating half is a Power Double Lock receptacle housing (e.g., 917350 series) with 12 circuits and 6.50 mm pitch, accepting the corresponding crimp terminals. The header's board guide helps align the receptacle during blind mating.
No official successor or pin-compatible cross-reference is listed — the Power Double Lock series is the only family match.
