8-Position Junior Timer Plug Housing
It accepts tab-style male contacts terminated via crimp, arranged in two rows. The housing is molded in yellow — a visual cue that helps trace circuits in multi-conductor harness assemblies. The 8 circuits and dual-row layout match the standard Junior Timer footprint used in automotive and industrial wire harnesses where a compact, keyed interconnect is needed. The free-hanging mount means no panel cutout — the housing clips into the harness routing and locks with the mating half via the integrated latch.
Procurement Note: Contacts Not Included
The crimp termination style means the harness builder selects the correct wire-gauge-specific terminal (typically from the Junior Timer contact family) and uses the matching crimp die to seat the wire. The yellow color, while not a functional spec, helps the assembly line distinguish this 8-position plug from other Junior Timer housings in the same harness bundle.
Regulatory and Lifecycle Status
The base product number is 927366.
This plug housing accepts tab-type male contacts (sold separately) terminated by crimp. The dual-row, 8-position layout mates with the matching Junior Timer receptacle housing. The free-hanging inline mount allows the connector to be positioned anywhere along the harness run, secured by the integrated latch. No panel cutout or additional mounting hardware is required.
