18-Position Harness-Side Receptacle for Junior Power Timer
The TE Connectivity 929504-6 is an 18-position receptacle housing from the Junior Power Timer series, designed as the harness-side half of a wire-to-wire or wire-to-board interconnect. The housing is free-hanging (inline), meaning it terminates a cable bundle and mates to a panel- or board-mounted header. Contacts are ordered separately — this is the shell only, in black PBT insulation rated UL94 V-0 for equipment inside enclosures.
What It Takes to Build This Connector
Because contacts are not included, you need to order the matching female crimp terminals separately — TE's Junior Power Timer terminal family, typically 17-20 AWG wire range. The crimp termination means you'll need a hand or pneumatic crimp tool on site to attach terminals to the wires, then insert them into the housing cavities. On the harness side, this mates with the corresponding Junior Power Timer header (same pitch, same row count) — confirm the header's mounting orientation (right-angle or vertical) matches your board edge or panel cutout.
