2.00mm pitch, 10-position breakaway header for signal-level board-to-board or cable interconnect
The 966926-5: It is unshrouded, push-pull fastening, and terminates via surface-mount solder. The current rating is 1A per contact at 250VAC, typical for low-power logic, sensor, or signal lines — not for power distribution. The breakaway design means this 10-position header is a snapped segment of a longer strip; the same base product number 966926 covers other position counts. The pick-and-place feature confirms it ships on tape-and-reel for automated assembly.
Gold mating finish and 1A current ceiling for signal duty
The tin-plated solder tails (98.4µinch) are standard for SMT reflow compatibility. The square male pin, 0.136 inch mating length, mates with standard AMPMODU receptacles or crimp-socket housings of the same pitch.
