1274670-1
TE Connectivity AMP Connectors
Board Edge, Cutout; Surface Mount-65°C ~ 165°CTape & Reel (TR) Cut Tape (CT)
Ref. price$2.2674
Lead time on requestGet quote
TE Connectivity AMP Connectors 1274 Series
8 variants · TE Connectivity AMP Connectors
About the TE Connectivity AMP Connectors 1274 Series
IC Source Direct is a China connector distributor, supplier and independent procurement agent for TE Connectivity AMP Connectors 1274 Series components, matching housing, contact and mating cycles across the Shenzhen interconnect channel. The TE Connectivity AMP Connectors 1274 Series series groups 8 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common IP rating of - and mating cycles of 500. Variants differ by body finish, body material and cable group, so you can match the exact body finish your application requires using the selection guide below. All listed TE Connectivity AMP Connectors 1274 Series part numbers are active and orderable.
Select a variant by
- Body finish
- Gold · Nickel · Tin
- Body material
- Brass · Steel
- Cable group
- - · AT&T 734A · RG-174, 316
- Center contact material
- Beryllium Copper · Brass · Copper Alloy · Phosphor Bronze
- Center contact plating
- Gold · Tin
- Connector type
- Jack, Female Socket · Plug, Male Pin · Receptacle, Non-Gendered
- Contact termination
- Crimp · Solder
- Dielectric material
- Liquid Crystal Polymer (LCP) · Polytetrafluoroethylene (PTFE)
Shared specifications
- IP rating
- -
- Mating cycles
- 500
Variant comparison
| Parameter | 1274670-1 | 1274568-2 | 1274714-2 | 1274727-1 | 1274531-1 | 1274572-1 |
|---|---|---|---|---|---|---|
| Body finish | Gold | Nickel | Gold | Nickel | Tin | Nickel |
| Body material | Brass | Brass | Brass | Brass | Brass | Brass |
| Cable group | - | AT&T 734A | - | - | - | - |
| Center contact material | Beryllium Copper | Phosphor Bronze | Beryllium Copper | Phosphor Bronze | Brass | Phosphor Bronze |
| Center contact plating | Gold | Gold | Gold | Gold | Gold | Gold |
| Connector type | Jack, Female Socket | Jack, Female Socket | Jack, Female Socket | Jack, Female Socket | Plug, Male Pin | Jack, Female Socket |
| Contact termination | Solder | Crimp | Solder | Solder | Solder | Solder |
| Dielectric material | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) |
Request a quote on any TE Connectivity AMP Connectors 1274 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
