1408348-1
TE Connectivity AMP Connectors
2 pcs - 1 Connector, 1 Contact-40°C~80°C50Ohm
Ref. price$18.6587
Lead time on requestGet quote ›
TE Connectivity AMP Connectors 1408 Series
43 variants · TE Connectivity AMP Connectors
About the TE Connectivity AMP Connectors 1408 Series
The TE Connectivity AMP Connectors 1408 Series series groups 43 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common center contact plating of Gold, fastening type of Snap-On and frequency - max of 6 GHz. Variants differ by body finish, body material and cable group, so you can match the exact body finish your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current TE Connectivity AMP Connectors 1408 Series variants and discontinued ones from a single page.
Select a variant by
- Body finish
- - · Gold · Nickel
- Body material
- - · Brass
- Cable group
- - · RD-316 · RG-58, 141, 303 · RG-174, 187, 316 · RG-174, 188, 316 · RG-178, 196 · RG-316 · RG-402 (.141\" Semi Rigid)
- Center contact material
- - · Beryllium Copper · Brass · Copper Alloy
- Connector type
- Jack, Female Socket · Plug, Male Pin · Receptacle, Female Socket
- Contact termination
- Crimp · Solder
- Dielectric material
- - · Polytetrafluoroethylene (PTFE)
- Features
- - · Extended Insulation
Shared specifications
- Center contact plating
- Gold
- Fastening type
- Snap-On
- Frequency - max
- 6 GHz
- Ingress protection
- -
- Number of ports
- 1
- Package
- Bulk
Variant comparison
| Parameter | 1408348-1 | 1408312-1 | 1408339-1 | 1408336-1 | 1408338-7 | 1408340-1 |
|---|---|---|---|---|---|---|
| Body finish | Gold | Gold | Nickel | Nickel | Nickel | Nickel |
| Body material | Brass | - | Brass | Brass | Brass | Brass |
| Cable group | RG-402 (.141\" Semi Rigid) | RG-316 | RG-174, 188, 316 | RG-174, 188, 316 | RG-58, 141, 303 | - |
| Center contact material | Beryllium Copper | - | Beryllium Copper | Brass | Beryllium Copper | Beryllium Copper |
| Connector type | Jack, Female Socket | Plug, Male Pin | Jack, Female Socket | Plug, Male Pin | Jack, Female Socket | Receptacle, Female Socket |
| Contact termination | Solder | Crimp | Solder | Solder | Solder | Solder |
| Dielectric material | Polytetrafluoroethylene (PTFE) | - | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) | Polytetrafluoroethylene (PTFE) |
| Features | - | - | - | - | - | Extended Insulation |
Request a quote on any TE Connectivity AMP Connectors 1408 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the TE Connectivity AMP Connectors 1408 Series variants differ?
- TE Connectivity AMP Connectors 1408 Series part numbers differ by body finish, body material, cable group and center contact material. Use the selection guide above to pick by body finish.
- How many TE Connectivity AMP Connectors 1408 Series part numbers are listed?
- 43 TE Connectivity AMP Connectors 1408 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for TE Connectivity AMP Connectors 1408 Series?
- Request a quote (RFQ) for any TE Connectivity AMP Connectors 1408 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
