5745071-4
TE Connectivity AMP Connectors
9TubeAMPLIMITE HD-20
Ref. price$6.9400
Lead time on requestGet quote ›
TE Connectivity AMP Connectors 5745 Series
48 variants · TE Connectivity AMP Connectors
About the TE Connectivity AMP Connectors 5745 Series
The TE Connectivity AMP Connectors 5745 Series series groups 48 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Black, contact form of - and gender of Signal. Variants differ by backset spacing, connector type and contact finish, so you can match the exact backset spacing your application requires using the selection guide below. All listed TE Connectivity AMP Connectors 5745 Series part numbers are active and orderable.
Select a variant by
- Backset spacing
- - · 0.318\" (8.08mm) · 0.590\" (14.99mm)
- Connector type
- Plug, Male Pins · Receptacle, Female Sockets
- Contact finish
- - · Gold
- Contact finish thickness
- - · 30.0µin (0.76µm) · Flash
- Contact material
- Brass · Phosphor Bronze
- Current rating
- - · 6A
- Dielectric material
- Polyamide (PA), Nylon · Polyamide (PA), Nylon, Glass Filled · Polyester · Thermoplastic
- Features
- - · Board Lock · Ground Strap
Shared specifications
- Color
- Black
- Contact form
- -
- Gender
- Signal
- Ingress protection
- -
- Rows
- 2
- Termination
- Solder
- Wire gauge
- -
Variant comparison
| Parameter | 5745071-4 | 5745076-6 | 5745781-6 | 5745185-7 | 5745784-4 | 5745001-2 |
|---|---|---|---|---|---|---|
| Backset spacing | - | - | 0.318\" (8.08mm) | - | 0.318\" (8.08mm) | 0.590\" (14.99mm) |
| Connector type | Plug, Male Pins | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Receptacle, Female Sockets | Plug, Male Pins |
| Contact finish | Gold | Gold | Gold | Gold | Gold | - |
| Contact finish thickness | Flash | 30.0µin (0.76µm) | 30.0µin (0.76µm) | Flash | 30.0µin (0.76µm) | - |
| Contact material | Brass | Phosphor Bronze | Phosphor Bronze | Phosphor Bronze | Phosphor Bronze | Brass |
| Current rating | 6A | 6A | 6A | 6A | 6A | - |
| Dielectric material | Polyester | Polyester | Thermoplastic | Polyamide (PA), Nylon, Glass Filled | Thermoplastic | Polyamide (PA), Nylon |
| Features | - | - | Ground Strap | - | Ground Strap | Board Lock |
Request a quote on any TE Connectivity AMP Connectors 5745 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the TE Connectivity AMP Connectors 5745 Series variants differ?
- TE Connectivity AMP Connectors 5745 Series part numbers differ by backset spacing, connector type, contact finish and contact finish thickness. Use the selection guide above to pick by backset spacing.
- How many TE Connectivity AMP Connectors 5745 Series part numbers are listed?
- 48 TE Connectivity AMP Connectors 5745 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for TE Connectivity AMP Connectors 5745 Series?
- Request a quote (RFQ) for any TE Connectivity AMP Connectors 5745 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
