Amphenol ICC (FCI) BergStik II header, order code 10119110-564003LF, 64 positions, dual row, 0.100" (2.54 mm) pitch, gold-plated mating contacts (30.0 µ in), through-hole right-angle, solder termination, unshrouded breakaway style.
Amphenol ICC (FCI) 10119110-564003LF BergStik II Header
MPN10119110-564003LF
Active
Amphenol ICC (FCI) BergStik II header, order code 10119110-564003LF, 64 positions, dual row, 0.100" (2.54 mm) pitch, gold-plated mating contacts (30.0 µ in), through-hole right-angle, solder termination, unshrouded breakaway style.
$9.2076Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 64 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.318\" (8.08mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
How do I get current pricing and availability for the 10119110-564003LF?
Submit an RFQ against the BOM quantity. The part ships in a bag package and is sourced per order.
What is the 10119110-564003LF's listed style?
The connector style is Board to Board, configured as a dual-row unshrouded header with breakaway capability.
