Amphenol ICC (FCI) Minitek® Pwr 3.0, 10127720-021LF, 2-position dual-row header, 0.118" (3.00 mm) pitch, through-hole right-angle, shrouded 4-wall, tin-plated male pins, board lock, locking ramp, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Minitek® Pwr 3.0 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC/DC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.285\" (7.25mm) |
| Insulation material | Liquid Crystal Polymer (LCP) |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Positions | 2 |
| Row spacing - mating | 0.118\" (3.00mm) |
| Contact length - post | 0.126\" (3.20mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 10127720-021LF: This is the 2-position member of the Minitek® Pwr 3.0 series from Amphenol ICC (FCI) — a dual-row, shrouded header with male square pins, through-hole right-angle termination, and a locking ramp for vibration-resistant mating.
Supplied in tray packaging.
The 10127720-021LF has 2 positions; the 10127720-041LF has 4 positions. Both share the same 3.00 mm pitch, tin plating, dual-row layout, right-angle through-hole mounting, board lock, and locking ramp.
Availability and current pricing confirmed at quote time.
