10129380-910001ALF — Amphenol product photo
Amphenol

10129380-910001ALF Amphenol ICC EconoStik 10-Pin SMT Header

MPN10129380-910001ALF
Active

Amphenol ICC (FCI) EconoStik 10129380, 10-position single-row unshrouded male pin header, 0.100" (2.54 mm) pitch, surface mount, gold-plated contacts, 3 A, 110 VDC, UL94 V-0, -55°C to 105°C.

$0.4400Ref. price · indicative, final on quote
10129380-910001ALF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10129380-910001ALF Technical Specifications
ParameterValue
SeriesEconoStik™ 10129380
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader, Cuttable
Fastening typePush-Pull
Voltage rating110VDC
Current rating3A
Operating temperature-55°C~105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTape & Reel (TR); Cut Tape (CT)
ShroudingUnshrouded
TerminationSolder
ApplicationsGeneral Purpose, Industrial, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions10
Contact finish - matingGold
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating1.00µin (0.025µm)

Product details

The 10129380-910001ALF: The connector is cuttable, meaning a single BOM line can serve multiple position counts by snapping the strip to length — useful for low-volume builds where inventory flexibility matters. Surface mount termination (SMT) allows reflow soldering, which reduces assembly labor and improves joint consistency compared to through-hole.

For higher cycle counts, consider a thicker gold option in the same series.

The voltage rating is 110 VDC, which is typical for signal-level circuits in general-purpose and medical applications. Current is limited to 3 A per contact; derate above 105°C ambient per the standard derating curve.

For a 6-position variant, see the 10129380-906001ALF or 10129380-906002ALF.

Frequently asked questions

What is the pitch of 10129380-910001ALF?

The mating pitch is 0.100" (2.54 mm), which is the standard 0.100-inch grid. This sets the board footprint and determines compatibility with matching receptacles.

Can 10129380-910001ALF be cut to smaller lengths?

Yes, the connector type is listed as Header, Cuttable. The single-row strip can be snapped to the desired position count, allowing one part number to cover multiple BOM lines.

How can I order 10129380-910001ALF or check stock?

This part is sourced per RFQ through independent distribution.
