IP67 USB-A stacked receptacle, 8 contacts, 1.5 A
The MUSBC511N0 is the 8-contact, single-port USB-A stacked receptacle in Amphenol ICC's MUSB series, specified to USB 2.0 and sealed to IP67 when mated.
MUSBC511N0 Amphenol ICC USB-A Stacked Receptacle, IP67
MPNMUSBC511N0
Active
Amphenol ICC (Commercial Products) MUSB USB-A (USB TYPE-A) stacked receptacle, order code MUSBC511N0, 8 contacts, 1 port, USB 2.0, gold-plated contacts, shielded, panel mount through-hole, solder termination, IP67.
$14.2900Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesMUSB
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | MUSB |
| Mounting | Panel Mount, Through Hole |
| Connector type | USB-A (USB TYPE-A), Stacked |
| Current rating | 1.5A |
| Positions | 8 |
| IP rating | IP67 - Dust Tight, Waterproof |
| Mounting feature | Flange, Vertical |
| Operating temperature | -40°C~105°C |
| Insulation color | Black |
| Shell (Shielding material) | Copper Alloy |
| Material flammability rating | UL94 V-0 |
| Gender | Receptacle |
All specifications
| Parameter | Value |
|---|---|
| Package | Box |
| Shielding | Shielded |
| Termination | Solder |
| Mating cycles | 1500 |
| Contact finish | Gold |
| Specifications | USB 2.0 |
| Number of ports | 1 |
