MUSB-D511-00
Amphenol
4Board LockTray
Ref. price$12.6200
Lead time on requestGet quote ›
Amphenol MUSB Series
52 variants · Amphenol
About the Amphenol MUSB Series
The Amphenol MUSB Series series groups 52 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common contact finish of Gold, gender of Receptacle and ingress protection of IP67 - Dust Tight, Waterproof. Variants differ by connector type, current rating and insulation color, so you can match the exact connector type your application requires using the selection guide below.
Select a variant by
- Connector type
- USB - mini B · USB-A (USB TYPE-A) · USB-A (USB TYPE-A), Stacked · USB-B (USB TYPE-B) · USB-C (USB TYPE-C)
- Current rating
- 0.25A, 1.25A, 5A · 1A · 1.5A
- Insulation color
- Black · White
- Mounting feature
- Flange, Horizontal · Flange, Vertical
- Mounting type
- Panel Mount, Through Hole · Panel Mount, Through Hole, Right Angle
- Operating temperature
- -40°C ~ 105°C · -40°C~105°C
- Package
- Box · Bulk · Tray
- Positions
- 4 · 5 · 8 · 24
Shared specifications
- Contact finish
- Gold
- Gender
- Receptacle
- Ingress protection
- IP67 - Dust Tight, Waterproof
- Material flammability rating
- UL94 V-0
- Number of ports
- 1
- Shielding
- Shielded
- Termination
- Solder
Variant comparison
| Parameter | MUSBA111M0 | MUSBA511N0 | MUSBA511N5 | MUSBB551N0 | MUSBD111M1 | MUSB-D511-00 |
|---|---|---|---|---|---|---|
| Connector type | USB-A (USB TYPE-A) | USB-A (USB TYPE-A) | USB-A (USB TYPE-A) | USB - mini B | USB-B (USB TYPE-B) | USB-B (USB TYPE-B) |
| Current rating | 1.5A | 1.5A | 1.5A | 1A | 1.5A | 1.5A |
| Insulation color | Black | Black | Black | Black | White | White |
| Mounting feature | Flange, Horizontal | Flange, Vertical | Flange, Vertical | Flange, Vertical | Flange, Horizontal | Flange, Vertical |
| Mounting type | Panel Mount, Through Hole, Right Angle | Panel Mount, Through Hole | Panel Mount, Through Hole | Panel Mount, Through Hole | Panel Mount, Through Hole, Right Angle | Panel Mount, Through Hole |
| Operating temperature | -40°C~105°C | -40°C~105°C | -40°C~105°C | -40°C~105°C | -40°C~105°C | -40°C ~ 105°C |
| Package | Bulk | Box | Box | Box | Box | Tray |
| Positions | 4 | 4 | 4 | 5 | 4 | 4 |
Request a quote on any Amphenol MUSB Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Amphenol MUSB Series variants differ?
- Amphenol MUSB Series part numbers differ by connector type, current rating, insulation color and mounting feature. Use the selection guide above to pick by connector type.
- How many Amphenol MUSB Series part numbers are listed?
- 52 Amphenol MUSB Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Amphenol MUSB Series?
- Request a quote (RFQ) for any Amphenol MUSB Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
