Amphenol ICC MUSB series USB 2.0 mini AB receptacle, order code MUSBE15134, 5 contacts, 1 A, gold-plated contacts, shielded, IP67-rated, panel mount through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | MUSB |
| Mounting | Panel Mount, Through Hole, Right Angle |
| Connector type | USB - mini AB |
| Current rating | 1A |
| Positions | 5 |
| IP rating | IP67 - Dust Tight, Waterproof |
| Mounting feature | Flange, Horizontal |
| Operating temperature | -40°C~105°C |
| Insulation color | Black |
| Shell (Shielding material) | Copper Alloy |
| Material flammability rating | UL94 V-0 |
| Gender | Receptacle |
| Parameter | Value |
|---|---|
| Package | Tray |
| Shielding | Shielded |
| Termination | Solder |
| Mating cycles | 5000 |
| Contact finish | Gold |
| Specifications | USB 2.0 |
| Number of ports | 1 |
The MUSBE15134 is the 5-contact mini AB receptacle in Amphenol ICC's MUSB series, specified for USB 2.0 and sealed to IP67 when mated. Gold-plated contacts and 5000 mating cycles suit it for repeated field connection in wet or dusty environments; the right-angle through-hole termination with flange mounting fixes the orientation at the panel face.
Amphenol ICC (Commercial Products) manufactures the MUSB series. Quoted to order against the BOM quantity; availability confirmed at RFQ.
Receptacle — mates with a mini AB plug.
