1.50mm pitch 11-position shrouded header for wire-to-board duty
The full 4-wall shrouding and detent lock keep the mated pair aligned and latched in moderate-vibration assemblies.
Pitch and position count define the footprint
The 1.50mm pitch and 11 positions loaded all set the PCB footprint. The contact length on the post is 0.118" (3.00mm) — enough for a standard 1.6mm board thickness with a solder fillet.
Shrouding and locking for reliable mating
The insulation height of 0.272" (6.91mm) leaves clearance for the mating housing latch.
