15-Position Shrouded Header for 1.50mm Pitch Wire-to-Board
The 1-292207-5 is a 15-position, single-row header from TE's Mini CT series, designed for board-to-cable/wire applications on a 1.50mm pitch.
Pitch, Positions, and Mating Half
At 1.50mm pitch, this header supports dense routing on the PCB — the 15 positions are all loaded, so the footprint matches the full pin count. The mating half is a Mini CT receptacle housing (e.g., 1-292227 series) with crimp terminals; the detent lock engages with the receptacle's latch feature.
Temperature Range and Material Ratings
The glass-filled nylon housing carries a UL94 V-0 flammability rating, and the tin-plated brass contacts (39.4µin mating finish) handle repeated mating cycles typical of field-serviceable connections.
