103166-7 TE AMPMODU Mod II Header, 18 Pos, Obsolete

MPN103166-7
Obsolete

TE Connectivity AMP Connectors AMPMODU Mod II header, order code 103166-7, 18 positions, dual row, 0.100" (2.54 mm) pitch, 3 A, gold-plated mating contacts, through-hole right-angle, solder termination, detent lock, tray.

$3.7300Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 103166-7 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026

Specifications

103166-7 key specifications
ParameterValue
SeriesAMPMODU Mod II
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeDetent Lock
Current rating3A
Operating temperature-65°C ~ 105°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.400\" (10.16mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

103166-7 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTray
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions18
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin-Lead
Contact length - post0.135\" (3.43mm)
Contact finish - matingGold
Contact length - mating0.318\" (8.08mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

18-position, 0.100" pitch, gold contacts

The 103166-7 is the 18-circuit member of the TE AMPMODU Mod II shrouded header line, mating with matching AMPMODU receptacles for board-to-board or cable connections. Gold-plated mating contacts rated 3 A per circuit, through-hole right-angle mounting with a detent lock for vibration resistance.

Obsolete — no direct replacement on record

TE Connectivity AMP Connectors lists the 103166-7 as Obsolete. No official successor or pin-compatible alternative is documented from the original manufacturer. A board spin may be required for a functional replacement.

Frequently asked questions

What is the closest pin-compatible alternative to 103166-7 in the AMPMODU Mod II family?

No pin-compatible alternative is documented from the original manufacturer. A board spin may be required for a functional replacement.
