Right-Angle 2.50mm Header for Board-Edge I/O
The 1376136-1 is a 6-position, 2-row header from TE's Dynamic D-2100 series, pitched at 2.50mm. It terminates through-hole with a right-angle orientation, so the mated cable exits parallel to the board — useful for keeping the connector low in a panel-mount enclosure. Rated 5 A per contact at 250 VAC, with gold-on-copper-alloy contacts (15.0 µin gold on the mating side) and tin on the solder posts. The 4-wall shrouding and detent lock protect against mis-mate and vibration release.
Board Lock and Shrouding for Industrial Fit
A board lock on the through-hole tails holds the header in place during wave solder and resists shear from cable strain. The 4-wall shroud and detent lock together prevent the mating plug from backing out under vibration — a common requirement in industrial control cabinets. The glass-filled polyester housing carries a UL94 V-0 flammability rating and operates from -55°C to 105°C, covering most indoor industrial and general-purpose environments.
