TE Connectivity AMP Connectors 1586041-8 — Pin Headers

1586041-8 TE Connectivity VAL-U-LOK Header, 8 Pos, 4.2 mm

MPN1586041-8
Active

TE Connectivity VAL-U-LOK 1586041-8, 8-position dual-row right-angle header, 4.20 mm pitch, tin-plated contacts rated 9 A per circuit at 600 VAC, shrouded four-wall housing with locking ramp, through-hole solder termination, -40 to 105 °C operating range.

$0.9600Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1586041-8 datasheet (PDF)
RoHSRoHS Compliant
SeriesVAL-U-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1586041-8 key specifications
ParameterValue
SeriesVAL-U-LOK
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating600VAC
Current rating9A
Operating temperature-40°C ~ 105°C
Contact materialBrass Alloy
Insulation colorNatural
Insulation height0.402\" (10.20mm)
Insulation materialPolyamide (PA), Nylon

All specifications

1586041-8 additional specifications
ParameterValue
Material flammability ratingUL94 V-2
StyleBoard to Cable/Wire
PackageBulk
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose, Industrial, Lighting
Contact shapeSquare
Rows2
Pitch0.165\" (4.20mm)
Positions8
Row spacing - mating0.165\" (4.20mm)
Contact finish - postTin
Contact length - post0.142\" (3.60mm)
Contact finish - matingTin
Contact finish thickness - post80.0µin (2.03µm)
Contact finish thickness - mating80.0µin (2.03µm)

Product details

Right-angle 8-position header — 4.20 mm pitch, 9 A per circuit

The 1586041-8: The 4.20 mm pitch and 9 A per circuit rating at 600 VAC suit it for general-purpose industrial and lighting applications where a reliable, vibration-resistant connection is needed.

Tin-plated contacts — 80 µin thickness, 9 A continuous

The through-hole, right-angle termination with a post length of 0.142" (3.60 mm) provides a robust solder joint for the PCB, and the 0.165" (4.20 mm) row spacing matches the pitch for consistent routing.

Frequently asked questions

Is 1586041-8 compatible with VAL-U-LOK plug housings?

Yes, the 1586041-8 is a shrouded header from the VAL-U-LOK series, designed to mate with VAL-U-LOK receptacle housings that accept the matching crimp terminals. The locking ramp on the header engages with the plug latch for a secure connection.
