TE Connectivity VAL-U-LOK 1586043-6, dual-row 6-circuit header, 4.20 mm pitch, right-angle through-hole, 9 A per contact at 600 VAC, tin-plated brass with locking ramp and mounting flange, -40 to 105 °C.
| Parameter | Value |
|---|---|
| Series | VAL-U-LOK |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC |
| Current rating | 9A |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass Alloy |
| Insulation color | Natural |
| Insulation height | 0.386\" (9.80mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-2 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Mounting Flange |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial, Lighting |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.165\" (4.20mm) |
| Positions | 6 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.142\" (3.60mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 80.0µin (2.03µm) |
| Contact finish thickness - mating | 80.0µin (2.03µm) |
The 1586043-6 is a dual-row, 6-position header from TE's VAL-U-LOK series, designed for wire-to-board power distribution. The 4.20 mm pitch and 9 A per contact rating place it in the mid-power class — not a signal-density header, but a workhorse for lighting, industrial controls, and general-purpose equipment.
The 1586043-6 is the male header half of the VAL-U-LOK system — it mates with the matching TE VAL-U-LOK female receptacle housing that accepts the corresponding crimp terminal and has a locking ramp slot. The 4-wall shroud on the header keys to the housing ribs to prevent mis-mating of adjacent circuit counts in the same series.
RoHS Compliant is the only compliance entry on the official lifecycle record. No UL, VDE, or IEC type-approval rating appears in the spec table. The UL94 V-2 flammability rating on the housing material is a material rating, not a connector agency listing — confirm with TE whether a UL recognition or VDE test report is available for the specific configuration before specifying in a certified end-product.
