TE Connectivity AMP Connectors High Performance Interconnect (HPI) series, 1734260-8, 8-position single-row shrouded header, 1.25mm pitch, SMD, tin-plated contacts, rated 1A per circuit at 125V, -25°C to 85°C, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | High Performance Interconnect (HPI) |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Voltage rating | 125V |
| Current rating | 1A |
| Operating temperature | -25°C ~ 85°C |
| Contact material | Phosphor Bronze |
| Insulation color | Natural |
| Insulation height | 0.187\" (4.75mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Solder Retention |
| Shrouding | Shrouded - 3 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Medical |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.049\" (1.25mm) |
| Positions | 8 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
The 1.25mm pitch and 8-position count define the PCB footprint; the SMT pads sit on a 1.25mm grid, single row. The insulation height of 0.187" (4.75mm) gives a low profile above the board, useful for tight enclosures.
Yes, 1734260-8 is RoHS compliant per the manufacturer listing.
