The 1734261-5: The 1.25 mm pitch and 5 positions define the PCB footprint — this is a compact single-row header for signal-level interconnects where board space is tight.
RoHS3 compliant, with no restricted substances above threshold levels.
1734261-5 TE Connectivity Header, SMT Right-Angle, 5 Pos
MPN1734261-5
Active
TE Connectivity AMP Connectors High Performance Interconnect (HPI) series, 1734261-5, board-to-cable/wire header, 5 positions, 1.25 mm pitch, surface mount right-angle, shrouded - 4 wall, tin-plated male pins, 1 A, 100 VAC, UL94 V-0.
$1.5400Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesHigh Performance Interconnect (HPI)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | High Performance Interconnect (HPI) |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Voltage rating | 100VAC |
| Current rating | 1A |
| Operating temperature | -25°C~85°C |
| Contact material | Phosphor Bronze |
| Insulation color | Natural |
| Insulation height | 0.136\" (3.46mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Medical |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.049\" (1.25mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
Product details
Frequently asked questions
Where can I buy 1734261-5 and what is the lead time?
No stock-holding claim is made — availability is verified per request.
