8-position Buchanan plug for unshrouded headers
The 1776263-8 is the 8-position member of TE's Buchanan plug line, a free-hanging (in-line) plug for unshrouded headers with a 0.197" (5.00mm) pitch.
TE 1776263-8 Buchanan Plug, 8 Pos, 5.00mm, 10 A
MPN1776263-8
Active
TE Connectivity AMP Connectors Buchanan plug, order code 1776263-8, 8 positions, single level, 0.197" (5.00mm) pitch, 10 A, 300 V, tin-plated brass contacts, free hanging (in-line), screw - leaf spring wire guard termination.
$3.8350Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Plug for Unshrouded Header |
| Series | Buchanan |
| Mounting | Free Hanging (In-Line) |
| Voltage - UL | 300 V |
| Current - UL | 10 A |
| Plug wire entry | 90° |
| Wire gauge or range - AWG | 16-24 AWG |
| Wire gauge or range - mm2 | 0.2-1.4mm² |
| Operating temperature | -40°C~105°C |
| Color | Blue |
| Contact material | Brass |
| Insulation height | 0.433\" (11.00mm) |
All specifications
| Parameter | Value |
|---|---|
| Pitch | 0.197\" (5.00mm) |
| Package | Bulk |
| Features | Interlocking (Side) |
| Screw size | M2.6 |
| Torque - screw | 0.34 Nm (3.0 Lb-In) |
| Number of levels | 1 |
| Termination style | Screw - Leaf Spring, Wire Guard |
| Positions | 8 |
| Positions per level | 8 |
| Contact mating finish | Tin |
