TE Connectivity AMP Connectors 2-1734248-4 — FFC / FPC Cable Assemblies

2-1734248-4 TE Connectivity FPC Connector 24 Pos 1.00mm ZIF

MPN 2-1734248-4
Active

TE Connectivity AMP Connectors FPC vertical SMD connector, 24 positions, 1.00 mm pitch, Zero Insertion Force (ZIF) slide lock, gold flash contacts, 1 A per contact, -20°C~85°C, UL94 V-0.

$2.2900 Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 2-1734248-4 datasheet (PDF)
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSRoHS Compliant
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

2-1734248-4 key specifications
ParameterValue
MountingSurface Mount
Cable end typeTapered
Flat flex typeFPC
Connector (Contact type)Contacts, Vertical - 1 Sided
Voltage rating125V
Current rating1A
Operating temperature-20°C~85°C
Housing colorBlack
Actuator colorBlack
Contact materialPhosphor Bronze
Housing materialPolyamide (PA9T), Nylon 9T
Actuator materialPolyamide (PA9T), Nylon 9T

All specifications

2-1734248-4 additional specifications
ParameterValue
Height above board0.217\" (5.50mm)
Material flammability ratingUL94 V-0
Pitch0.039\" (1.00mm)
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesZero Insertion Force (ZIF)
TerminationSolder
Mating cycles20
Contact finishGold
Locking featureSlide Lock
FFC, FCB thickness0.30mm
Positions24
Contact finish thicknessFlash

Product details

The 2-1734248-4: With 24 positions, it handles a moderate-density signal bundle without crowding the board edge. The vertical orientation (contacts perpendicular to the PCB) keeps the FPC standing upright, useful when the cable exits straight off the board into a tight enclosure.

ZIF Slide Lock and Cable Retention

Zero Insertion Force (ZIF) actuation means the FPC slides in without scraping the contact pads — the slide lock then clamps the cable in place.

Gold flash (thin gold over nickel) provides corrosion resistance for occasional mating, but the 20-cycle rating means this connector is not designed for frequent disconnect in the field.

RoHS compliant, housing rated UL94 V-0.

Frequently asked questions

Can 2-1734248-4 be used as a replacement for a failed FPC connector?

Yes, if the original connector is a 1.00 mm pitch, 24-position vertical SMD ZIF type accepting 0.30 mm FPC. The gold flash contacts and 20-cycle rating mean it suits low-service-life applications where the FPC is not frequently disconnected.
