284506-2
TE Connectivity AMP Connectors
2Side StackingPlug, Female Sockets
Ref. price$1.2300
Lead time on requestGet quote ›
TE Connectivity AMP Connectors 2845 Series
62 variants · TE Connectivity AMP Connectors
About the TE Connectivity AMP Connectors 2845 Series
The TE Connectivity AMP Connectors 2845 Series series groups 62 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common color of Green, contact material of Phosphor Bronze and contact mating finish of Tin. Variants differ by operating temperature, pitch and positions, so you can match the exact operating temperature your application requires using the selection guide below.
Select a variant by
- Operating temperature
- -40°C ~ 110°C · -40°C~110°C
- Pitch
- 0.138\" (3.50mm) · 0.150\" (3.81mm)
- Positions
- 2 · 3 · 4 · 5 · 6 · 8 · 9
- Positions per level
- 2 · 3 · 4 · 5 · 6 · 8 · 9
Shared specifications
- Color
- Green
- Contact material
- Phosphor Bronze
- Contact mating finish
- Tin
- Contact tail length
- -
- Current - IEC
- -
- Current - UL
- 11 A
- Features
- Side Stacking
- Header orientation
- -
- Housing material
- Polyamide (PA66), Nylon 6/6
- Ingress protection
- -
- Insulation height
- 0.437\" (11.10mm)
- Material flammability rating
- UL94 V-0
Variant comparison
| Parameter | 284506-2 | 284506-3 | 284506-4 | 284506-5 | 284506-6 | 284506-8 |
|---|---|---|---|---|---|---|
| Operating temperature | -40°C ~ 110°C | -40°C ~ 110°C | -40°C ~ 110°C | -40°C ~ 110°C | -40°C ~ 110°C | -40°C ~ 110°C |
| Pitch | 0.138\" (3.50mm) | 0.138\" (3.50mm) | 0.138\" (3.50mm) | 0.138\" (3.50mm) | 0.138\" (3.50mm) | 0.138\" (3.50mm) |
| Positions | 2 | 3 | 4 | 5 | 6 | 8 |
| Positions per level | 2 | 3 | 4 | 5 | 6 | 8 |
Request a quote on any TE Connectivity AMP Connectors 2845 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the TE Connectivity AMP Connectors 2845 Series variants differ?
- TE Connectivity AMP Connectors 2845 Series part numbers differ by operating temperature, pitch, positions and positions per level. Use the selection guide above to pick by operating temperature.
- How many TE Connectivity AMP Connectors 2845 Series part numbers are listed?
- 62 TE Connectivity AMP Connectors 2845 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for TE Connectivity AMP Connectors 2845 Series?
- Request a quote (RFQ) for any TE Connectivity AMP Connectors 2845 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
