Amphenol ICC (FCI) Clincher series, 0.100" (2.54mm) pitch, 7-position FFC header, 2 A per contact, 500 V, tin-plated contacts, ZIF flip-lock actuator, free-hanging solder termination, UL94 V-0 housing.
| Parameter | Value |
|---|---|
| Series | Clincher™ |
| Mounting type | Free Hanging (In-Line) |
| Cable end type | Tapered |
| Flat flex type | FFC |
| Connector (Contact type) | Header |
| Voltage rating | 500V |
| Current rating | 2A |
| Operating temperature | -65°C~105°C |
| Housing color | Blue |
| Actuator color | Black |
| Contact material | Copper Nickel Alloy |
| Housing material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.100\" (2.54mm) |
| Package | Tray |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Termination | Solder |
| Mating cycles | 100 |
| Contact finish | Tin |
| Locking feature | Flip Lock, Backlock |
| FFC, FCB thickness | 0.30mm |
| Positions | 7 |
| Contact finish thickness | 100.0µin (2.54µm) |
The ZIF actuator uses a flip lock with a backlock feature — the FFC inserts with zero insertion force, then the actuator locks the cable in place.
It is RoHS compliant.
The flip lock and backlock keep the FFC seated under vibration.
The pitch is 0.100" (2.54mm). This sets the FFC cable pitch and the board footprint for the solder termination.
Yes, the 66226-007LF is RoHS compliant.
Yes, it has a flip lock and a backlock — a ZIF actuator that holds the FFC without insertion force and prevents it from backing out.
The closest functional equivalent within the same Clincher series is the 66226-006LF (6 positions). The 66226-005LF (5 positions) and 66226-004LF (4 positions) are also available — all share the same pitch, current, voltage, and locking feature.
